Capabilities

LASER & PLASMA CUTTING
• Mitsubishi LVPlus 3050 Laser

      • 5’x10′ 5000 Watt (Peak Power)

      • Hi-Speed open style pallet changer

      •  2-5′ x 10′ Shuttle tables

      • Diamonds Path Advanced Beam Delivery

      • Precise Positioning Accuracy

      • Carbon Steel 1″, Stainless 1/2″, Aluminum 3/8″



• AKS Cutting Systems “robo-kut”

The AKS “robo-kut” is designed with robotic style

precision gearing that can be incremented in

arc-seconds, or fractions of degrees, for the tightest precision and accuracy in the industry.
      • Features:
      • Robust, Rigid and Compact and sealed for Protection

        and Cleanliness

      • Machined Solid Billet Aluminum Block without

        weldments or stamped parts, like competitive cutting

        heads

      • Compact Lightweight High-Tech Design weighing less

      than 50 lbs.

More about the AKS "robo-kut"


SHEARING/PUNCHING
Accushear Hydraulic Shear
     • 1/4″ x 10′ Shearing Capacity (Mild Steel)
      • 8′ Squaring Arm
      • Programmable “Go To” Back Gage
      • Adjustable Rake/Blade Clearance

Mubea Profi 500 Ironworker (Capacities in Mild Steel)
      • Shearing: 14″ Wide x 5/8″ Thick Mild Steel
      • Notching: 5/16″ Thick Mild Steel
      • Angle Shearing: 5″ x 5″ x 3/8″ Thick Mild Steel
      • Round/Sq. Stock Cutoff: 1 1/8″ Dia./ Mild Steel
      • Punching:  up to 1-1/4” Hole


METAL FORMING

250 Ton 12′ Accurpress Press Brake
       • ETS 3000 Programming Controller
       • 3 Axis Programmable Back Gage System


       • Programmable Anti-Crowning System
       • 4 way bottom die system

130 Ton Accurpress Press Brake
        • 2 Axis CNC Back Gage (99 Stored programs)
        • 4 way Bottom Die System
        • Manual Anti-Crowning System

• Tennsmith 10′ Manual Brake

• Tennsmith 4′ Finger Brake



TUBE & PIPE BENDING

• Baleigh Model RDB-350 Rotary Draw Bender

    • Bend Tech Programming Software

    • ½” to 2-1/2” Schedule 40 Pipe

    • 2” x 1/8” wall Square Tube Bending

• 2516-H Compact Rotary Bender
    • 5/16″ x 2″ Flat Bar (Mild Steel)
    • 5/6″ Round or Square Stock (Mild Steel) should

       be ½” not 5/6”
    • 1/2″, 3/4″, 1″ Diameter tube



PLATE ROLLING

• Heller 5/16″ X 60″ Initial Plate Roll

• Tennsmith 36″ Manual

• Heller 16 ga. x 60″ Power Roller

Eagle BPR Pyramid Roller CP30
    • Rolls: 1-1/2” Pipe, 1-1/2” Angle, 1-1/2” Square Tube
      and up to 3-5/8” Flats








MACHINING

Haas VF-1 Vertical Machining Center

     20″(X) x 16″(Y) x 20″(Z)

     20 ATC Tool Changer

     Cat 40 Tool Holders

     • Programmable Coolant * Quick Code

SAWING
 Doringer D350 Heavy Duty Cold Saw
      • Automatic Coolant * Air Vise


      • SawGear Auto Length Measuring System
Hem Sidewinder
      • Automatic Feed (up to 24”)
      • 12” Diameter Capacity
      • Bundle Cutting Capability
      • Out Of Stock Shut Off
Roll-in Model EF


      • 14 1/2″ Vertical / 8-3/4″ Throat Capacity

 BLAST-PAINT-BAKE
9′ x 13′ x 26′ Blast Booth w/ Dust Collection

         • Automatic Dust Control System
         • Media Reclaiming Feature
2-2′ x 4′ Econoline Blasting Cabinets
11′ x 14′ x 26′ Paint Booth and
• 10′ x 13′ x 26′ Bake Booth w/1million BTU heat
         • Make up air ventilation system in both units.
         • 10’ x 13’ booth has heated drying up to 165 degrees
         • Ability to Paint Wet Coat Paint Products (latex,

           enamels, urathanes)

 WELDING

• Miller XMT 350 CC/CV  W/S-74DX Feeder

• Miller 252x MIG Welders

• 20 KVA Miller Spot Welder W/ water coolant
• Lincoln Inverter V-205 AC/DC TIG
• Lincoln Squarewave 255 TIG AC/DC with pulse

• Lincoln Squarewave 275 TIG AC/DC with pulse
• Lincoln 350 AC/DC Pulse MIG Welder

• Lincoln SP100 MIG DC

DRILLING
• American Hole Wizard Radial Drill
    • Self Feeding
    • Tapping Capable

    • “T” slot table for jigging/holding

• Summit Gear Head Drill Press TCA-45
    • Self Feeding
    • Tapping Capable

    • ¾” chuck,

• Ellis Model 9000
    • Drilling Capable – 1-1/16″ Steel
    • Rigid tapping Capacity: 3/4″ Steel

COMPUTERS
CAD/CAM w/ telecom transfer (Auto-Cad, DXF)
Pre-Loaded Parts Library and CAD Capabilities
All Processes managed w/ Job Boss Software
